A Comparative Study on the Developmental Anatomy of Embryos from Gabengcui Jujube and Golden‐silk Jujube

doi:10.15933/j.cnki.1004-3268.2025.04.011

Abstract

Abstract: To investigate the period of embryo failure in Golden‐silk jujube and discuss the causes of such failure，in this study，external morphological and anatomical observations were made on two varieties of jujube，Gabengcui jujube and Golden‐silk jujube，during different developmental periods.The results showed that the development trend of young fruits of Golden‐silk jujube from 3 d after flowering to 35 d after flowering was smooth，and the development trend of Gabengcui jujube was slow‐fast，and the fruit development of Gabengcui jujube was faster than that of Golden‐silk jujube.And 30 percent of Gabengcui jujube had tridentate split stigmas.Anatomical observation found that Golden‐silk jujube and Gabengcui jujube ovary had two compartments，each bearing an anatropous ovule，but Gabengcui jujube had phenomenon of double embryonic compartments and three ovules with a 30% incidence.In most of the fruits an ovule shrivelled，forming a single ovule.At the beginning of the embryo development process，the endosperm development of Golden‐silk jujube was obviously slower than that of Gabengcui jujube，while the embryo development of Golden‐silk jujube was faster than that of Gabengcui jujube；endosperm disintegration，ovule atrophy and embryo failure phenomenon appeared in Golden‐silk jujube at 30 d after flowering，and the endosperm，ovule and embryo of Golden‐silk jujube disappeared at 35 d after flowering.The embryo，endosperm and bead centre of Gabengcui jujube developed normally.On the whole，the fruit development of Gabengcui jujube was faster than that of Golden‐silk jujube.The embryo abortion time of Golden‐silk jujube was 30 d after flowering，and both endosperm and embryo were aborted.

Key words: Ziziphus jujuba Mill, Embryo development, Morphological observation, Anatomical observation

摘要： 为了探究金丝小枣胚败育的时期和败育原因，对金丝小枣和嘎嘣脆枣2个品种不同发育时期进行外部形态学和解剖学观察。结果表明，金丝小枣从花后3 d到35 d幼果发育平缓，嘎嘣脆枣幼果发育趋势为慢-快，且嘎嘣脆枣的果实发育比金丝小枣快。嘎嘣脆枣中30%出现三叉分裂柱头。解剖学观察发现，金丝小枣与嘎嘣脆枣子房两室均着生一倒生胚珠，嘎嘣脆枣的胚室中有30%发生双胚室三胚珠现象，其中多数果实一胚珠萎缩，形成单胚珠。胚发育过程初期金丝小枣胚乳发育明显慢于嘎嘣脆枣，而胚发育快于嘎嘣脆枣；花后30 d金丝小枣出现胚乳解体、珠心萎缩和胚败育现象，花后35 d胚乳、珠心和胚消失。嘎嘣脆枣胚与胚乳、珠心均正常发育。整体上看嘎嘣脆枣果实发育快于金丝小枣，金丝小枣胚败育时间为花后30 d，且胚乳与胚均败育。

关键词: 枣, 胚发育, 形态学观察, 解剖学观察

CLC Number:

S665.1

CHEN Zizhu, QING Jun, BAO Wenhui, WANG Yaping, GE Genzhula, BAI Yu’e. A Comparative Study on the Developmental Anatomy of Embryos from Gabengcui Jujube and Golden‐silk Jujube[J]. Journal of Henan Agricultural Sciences, 2025, 54(4): 109-116.

陈紫竹, 庆军, 包文慧, 王亚萍, 格根珠拉, 白玉娥. 嘎嘣脆枣和金丝小枣胚的发育解剖学比较研究[J]. 河南农业科学, 2025, 54(4): 109-116.

Figures/Tables 5

References

［1］苏彩霞，郭凯勋，刘晓红.我国红枣产业的现状、存在问题及对策［J］.果农之友，2020（2）：39‐41.
SU C X，GUO K X，LIU X H.Current situation，existing problems and countermeasures of Chinese jujube industry［J］.Fruit Growers’Friend，2020（2）：39‐41.
［2］闫旭宇，李娟，李玲，等.枣胚败育因素分析及提高幼胚发生的措施［J］.种子，2020，39（8）：52‐55，60.
YAN X Y，LI J，LI L，et al.Analysis of abortive factors of jujube embryo and measures to improve the development of young embryo［J］.Seed，2020，39（8）：52‐55，60.
［3］张冬野，高萌，李胜男.植物种胚败育机理研究进展［J］.东北农业大学学报，2021，52（11）：89‐96.
ZHANG D Y，GAO M，LI S N.Research progress on mechanism of plant embryo abortion［J］.Journal of Northeast Agricultural University，2021，52（11）：89‐96.
［4］STEPHENSON A G. Flower and fruit abortion：Proximate causes and ultimate functions［J］.Annual Review of Ecology and Systematics，1981，12（1）：253‐279.
［5］张丽梅，余东，陈志峰，等.“爱文”杧正常果和败育果发育动态及内含物差异性研究［J］.中国南方果树，2019，48（5）：44‐47.
ZHANG L M，YU D，CHEN Z F，et al.Study on developmental dynamics and differences of contents between normal and abortive fruits of“Aiwen”mango［J］.South China Fruits，2019，48（5）：44‐47.
［6］杨晋彬.小麦雌性不育系子房发育的观察与分析［D］.乌鲁木齐：新疆农业大学，2008.
YANG J B.Observation and analysis of ovary development on the female sterile line in wheat（Triticum aestivum L.）［D］.Urumqi： Xinjiang Agricultural University，2008.
［7］李叶蓓，刘希伟，张炳超，等.玉米受精和早期子粒发育过程及逆境胁迫对其影响［J］.玉米科学，2020，28（2）：76‐83.
LI Y B，LIU X W，ZHANG B C，et al.Maize fertilization and early stage of seed development and impacts on them exposed to stresses［J］.Journal of Maize Sciences，2020，28（2）：76‐83.
［8］CHEN Y Q，DU B S，WANG S G，et al.Histological characteristics and related gene expression analysis of ovule abortion in Camellia oleifera［J］.Journal of Beijing Forestry University，2023，45（9）：9‐20.
［9］赵艳卓，陈展，牛早柱，等.胚挽救技术在我国无核葡萄育种中的应用及展望［J］.河北农业科学，2019，23（1）：78‐84.
ZHAO Y Z，CHEN Z，NIU Z Z，et al.Application and prospects of embryo rescue technology in seedless grape breeding in china［J］.Journal of Hebei Agricultural Sciences，2019，23（1）：78‐84.
［10］顾爱侠，冯大领，轩淑欣，等.胚挽救技术在植物育种中的应用［J］.河北林果研究，2010，25（1）：30‐33.
GU A X，FENG D L，XUAN S X，et al.Application of embryo rescue technique in plant breeding［J］.Hebei Journal of Forestry and Orchard Research，2010，25（1）：30‐33.
［11］张文颖，王晨，汤崴.果树果实胚败育研究进展［J］.分子植物育种，2018，16（12）：4043‐4054.
ZHANG W Y，WANG C，TANG W.Advances study on embryo abortion of fruit trees［J］.Molecular Plant Breeding，2018，16（12）：4043‐4054.
［12］刘玲，王玖瑞，刘孟军，等.枣不同品种花粉量和花粉萌发率的研究［J］.植物遗传资源学报，2006，7（3）：3338‐3341.
LIU L，WANG J R，LIU M J，et al.Pollen number and its germination rate of different Chinese jujube cultivars［J］.Journal of Plant Genetic Resources，2006，7（3）：3338‐3341.
［13］吴硕，贾彦丽，智福军，等.18个枣品种花粉数量与萌发率的研究［J］.河北农业科学，2017，21（1）：42‐45.
WU S，JIA Y L，ZHI F J，et al.Pollen number and its germination rate of eighteen Chinese jujube cultivars［J］.Journal of Hebei Agricultural Sciences，2017，21（1）：42‐45.
［14］邵凤侠，王森，陈建华，等.‘中秋酥脆枣’雄蕊形态发育特性及花粉活力［J］.植物生理学报，2020，56（1）：16‐31.
CHAO F X，WANG S，CHEN J H，et al.Stamen morphological development and pollen viability of Ziziphus jujuba Zhongqiusucui［J］.Plant Physiology Journal，2020，56（1）：16‐31.
［15］张学英，王秀伶，彭士琪.枣不同品种花粉生活力和胚囊败育率的研究［C］//中国园艺学会，河北农业大学.首届全国干果生产与科研进展学术研讨会论文集.保定：中国林业出版社，1998：3.
ZHANG X Y，WANG X L，PENG S Q.Study on pollen viability and embryo sac abortion rate of different jujube varieties［C］//Chinese Society of Horticulture，Agricultural University of Hebei.Proceedings of the first National Symposium on Dried Fruit Production and Scientific Research Progress. Baoding：China Forestry Publishing House，1998：3.
［16］侯思皓，张钟，李一荷.枣自交与异交花粉管生长行为及早期胚胎发育研究［J］.果树学报，2019，36（11）：1515‐1523.
HOU S H，ZHANG S，LI Y H.Observation of pollen tubes behavior and early embryogenesis following self and cross‐pollination in Chinese jujube［J］.Journal of Fruit Science，2019，36（11）：1515‐1523.
［17］张学英，彭士琪，郭振怀.枣授粉受精及胚胎发育研究［J］.林业科学，2004，40（5）：210‐212.
ZHANG X Y，PENG S Q，GUO Z H.Studies on the pollination，fertilization and embryo development of Chinese date ‘Wu‐He‐Zao’（Ziziphus jujuba）［J］.Forestry Science，2004，40（5）：210‐212.
［18］邵凤侠.南方鲜食枣胚败育机理研究［D］.长沙：中南林业科技大学，2021.
SHAO F X.Research on the mechanism of embryo abortion of southern china fresh‐eat jujube［D］.Changsha：Central South University of Forestry and Technology，2021.
［19］SIENNA T O，SHARON A K.Update on signaling pathways regulating polarized intercellular communication in Arabidopsis reproduction［J］.Plant Physiology，2023，193（3）：1732‐1744.
［20］NIU Y F，PENG J Y，LI L.Study on morphology of flower organ and anatomical characteristics of microspore different developmental period in Chinese jujube and wild jujube［J］.Journal of Plant Genetic Resources，2011，12（1）：158‐162.
［21］祁永梁，李亚鹏，李世安，等.槲树不同发育时期胚珠石蜡切片制备体系的优化［J］.西北农林科技大学学报，2024，52（7）：1‐9.
QI Y L，LI Y P，LI S A，et al.Optimizing preparation system of ovules paraffin sections of Quercus dentata Thumb.in different development stages［J］.Journal of Northwest A&F University，2024，52（7）：1‐9.
［22］黄文辉，马学忠，林朝楷.南酸枣‘林枣1号’良种选育［J］.林业科技通讯，2022（5）：57‐59.
HUANG W H，MA X Z，LIN Z K.Breeding of good cultivars of Choerospondias axillaris‘Linzao 1’［J］.Practical Forestry Technology，2022（5）：57‐59.
［23］张雁飞，靳娟，阿布都卡尤木·阿依麦提，等.赛蜜酥1号枣及其芽变的表型和光合差异比较［J］.新疆农业科学，2023，60（1）：69‐78.
ZHANG Y F，JIN J，ABUDUKAYOUMU A，et al.Comparison of phenotypic and photosynthetic differences between Saimisu 1 jujube and its budding［J］.Xinjiang Agricultural Sciences，2023，60（1）：69‐78.
［24］王玉武.浅析大樱桃落花落果原因及综合防治［J］.果树资源学报，2023，4（1）：60‐62.
WANG Y W. Analysis of the causes and comprehensive prevention and control of cherry fruit［J］.Journal of Fruit Tree Resources，2023，4（1）：60‐62.
［25］任海燕，李登科，王永康.迎秋红枣的柱头形态变化及早期胚胎发育研究［J］.果树学报，2022，39（4）：602‐609.
REN H Y，LI D K，WANG Y K.Stigma morphological changes and early embryogenesis development of Yingqiuhong Chinese jujube（Ziziphus jujuba Mill.）［J］.Journal of Fruit Science，2022，39（4）：602‐609.
［26］梁春莉.枣种质胚败育普查［J］.辽宁农业职业技术学院学报，2013，15（6）：14‐16.
LIANG C L.Survey of embryo abortion of jujube germplasm［J］.Journal of Liaoning Agricultural Vocational and Technical College，2013，15（6）：14‐16.
［27］石东里，姚志刚，申保忠.枣品种含糖量的测定与比较［J］.滨州学院学报，2005，21（3）：59‐61.
SHI D L，YAO Z G，SHEN B Z.Determination and comparison of sugar content of jujube varieties［J］.Journal of Binzhou College，2005，21（3）：59‐61.
［28］黄丽君，罗培四，卢美瑛，等.苹婆种实生长发育过程中其形态及种仁内含物的动态变化［J］.经济林研究，2023，41（4）：126‐132.
HUANG L J，LUO P S，LU M Y，et al.Dynamics of fruit seeds growth and internal substances for Sterculia
monosperma’s fruits and seeds［J］.Economic Forest Research，2023，41（4）：126‐132.
［29］ZHONG S，LI L，WANG Z J，et al.RALF peptide signaling controls the polytubey block in Arabidopsis［J］.Science，2022，375（6578）：290‐295.
［30］马兆惠，石一涵，程海涛，等.水稻种子胚形态与胚乳组成对稻米留胚特性的影响［J］.中国水稻科学，2023，37（3）：265‐275.
MA Z H，SHI Y H，CHENG H T，et al.Effects of embryo morphology and endosperm composition on embryo‐remaining characteristics in rice［J］.Chinese Rice Science，2023，37（3）：265‐275.
［31］BRINK R A，COOPER D C.The endosperm in seed development［J］.The Botanical Review，1947，13：479‐541.
［32］王近卫，堀内昭作，林伯年，等.无核白葡萄的无核果形成的组织形态学研究［J］.园艺学报，1992，19（1）：1‐6.
WANG J W，HORIUCHI S S K，LIN B N，et al.Histomorphological study on the formation of drupeless fruit in seedless white grape［J］.Acta Honrticulturae Sinica，1992，19（1）：1‐6.
［33］刘小宁，王跃进，张剑侠，等.Flame Seedless葡萄胚珠、胚乳及胚发育与败育的研究［J］.西北植物学报，2005，25（10）：1947‐1953.
LIU X N，WANG Y J，ZHANG J X，et al.Development and abortion of the ovules，endosperms and embryos of Flame Seedless grape［J］.Acta Botanica Boreali‐Occidentalia Sinica，2005，25（10）：1947‐1953.
